PCCOOLER E91M 90mm 4PIN PWM CPU Cooler for Intel LGA 1151-1150-1155-1156-775 & AMD AM4-FM2 -FM2-FM1-AM3 AN3-AM2 AM2

Used as a fastening solution to secure medium weight fixtures through insulation boards without creating a thermal bridge.

$ 11.18

Supplied in units of 10 fixings per box. Lengths range from 80 mm to 280 mm .

Detailed Product Information

Description Specifications Mfr Part Number: E91M Features: Aluminum fins are designed for maximum cooling while switching noise free, 90 mm fan minimizes noise and cools not only the CPU but also provides powerful peripheral cooling Hydraulic Bearing The CPU cooler’s height is 52 mm and designed to be installed in ATX cases as well as slim or LP (low profile) cases Multi-platform Compatible CPU Compatibility: Intel: LGA1156/ 1155/ 1151/ 1150/ 775 AMD: AM4/ AM3 / AM3/ AM2 / AM2/ FM2 / FM2/ FM1 TDP: 66W Heatsink Material: Aluminum Heat Base Material: 36 x 41mm Aluminum  Heat Pipes: N/A Surface Treatment: Anti-oxidation Protective Layer RGB Version: N/A Included Fans: 1pcs Fan Speed: 2000 ± 10%RPM Air Flow: 45.6CFM (Max) Static Pressure: 1.95mmH20 (Max) Noise Level: 25.0 dBA Rated Voltage: 12VDC Operating Voltage: 8~13.2VDC Started Voltage: 7.5VDC Rated Current: 0.18 A (Fan Moto) Power Input: 2.16 W Bearing Type: Hydraulic Bearing Fan Dimensions: 90.0 x 90.0 x 25.0 mm Dimensions (WxLxH): 112.0 x 127.0 x 57.0 mm (Overall) Weight: 225.0 g
