Solid Gear SDGR-FLEX270 270W Mini-ITX – FLEX ATX Power Supply
Used as a fastening solution to secure medium weight fixtures through insulation boards without creating a thermal bridge.
$ 31.87
Supplied in units of 10 fixings per box. Lengths range from 80 mm to 280 mm .
Detailed Product Information
Description Specifications Mfr Part Number: SDGR-FLEX270 Features: Mini-ITX/FLEX ATX type Supports Intel & AMD Socket Low ripple and noise Over voltage protection Over power protection 100% hi-pot test Short Circuit protection Thermal overload cut-off protection Stained SECC Steel Material 15″ long cables Energy efficiency Maximum Power: 270W Input: Voltage: 100-240V Current: 100A max cold start Frequency Range: 47/63Hz Regulation: Line: /-1% typical Load: /- 5% typical Output Ripple: Noise – 1% Fan: 1x 40mm Cooling Fan Output: 3.3V @ 9A, 5V @ 12A, 12V @ 14A, -12V @ 0.3A, -5V @ 0.1A, 5Vsb @ 2.0A Connectors: 1x 20 4pin Main Connector, 1x 4pin 12V Connector, 2x 15pin SATA Connectors, 2x 4pin Molex Connectors, 1x 4pin Floppy Connector MTBF (Full Load): > 20,000 Hours EnergystarStand by: < 1W Dimensions (WxDxH): 3.250 x 6.000 x 1.625 inch Weight: 2.0 lbs
