Dynatron G555 2U CPU Fan For Intel Xeon 5500 Series LGA1366 CPU

Used as a fastening solution to secure medium weight fixtures through insulation boards without creating a thermal bridge.

$ 31.30

Supplied in units of 10 fixings per box. Lengths range from 80 mm to 280 mm .

Detailed Product Information

Description Specifications Mfr Part Number: G555 CPU Application: Intel Xeon 5500 Series Nehalem EP Processor Socket LGA 1366 for 2U Server & Up Material: Copper Base & Aluminum Fins with Heatpipes embeded Fan: Speed: 1000 ~ 5500 rpm Bearing: 2x Ball Rated Voltage: 12 V Power: 0.54 ~ 9 W Air Flow: 8.36 ~ 53.899 cfm Noise Level: 20.6 ~ 51.4 dBA Air Pressure: 0.009 ~ 0.220 inch-H2O Lead Wire Pin Out: Pin1-Black (-); Pin2-Yellow ( ); Pin3-Green (Techometer/Signal output); Pin4-Blue (PWM) Dimensions: Fan: 77 x 77 x 20 mm Overall: 94 x 89.5 x 64 mm Weight: 460 g

Product Documentation
